Altum RF Introduces Low Noise Amplifiers for E-Band applications
(EINDHOVEN, NETHERLANDS) May 24, 2024 – Altum RF, a supplier of high-performance RF to millimeter-wave semiconductor solutions for next generation markets and applications, announces E-band LNAs available as bare die and packaged devices.
Altum RF’s ARF1206 E-band low-noise amplifier is suitable for a variety of demanding telecommunications and sensing applications. It features 20 dB typical gain with 2.5-3.5 dB noise figure from 71-86 GHz and operates off a single 4V supply. It is pre-matched on the input and output to 50 Ω with integrated ESD-protection.
This part is fabricated using GaAs technology and is also available in a 5×5 mm² surface mount package, the ARF1206L5.
| Part number | Frequency Range (GHz) | Gain (dB) | P1dB (dBm) | NF (dB) | Bias Voltage (V) | Bias Current (mA) | Package | Sampling |
| ARF1206 | 71-86 | 20 | 12 | 2.5 – 3.5 | 4 | 45 | Bare Die | NOW |
| ARF1206L5 | 71-86 | 18 | 12 | 3.0 – 4.5 | 4 | 45 | 5 x 5 mm | NOW |
